In this guide, I’ll be taking apart a Lenovo ThinkPad X250 in order to access and upgrade the hard drive, SSD and RAM.

• Lenovo X250 M.2 Slot Ssd
• Lenovo X250 M.2 Slot 1tb

Looking for more guides from laptopmain.com? Follow us on Facebook for all the latest teardown news.

It’s used as the primary tool to differentiate the configurations in models of current and withdrawn Lenovo products. Currently PSREF only covers commercial products (Think products and Lenovo V series) launching in EMEA, Think products launching in United States, and web publish models of consumer products launching in United States and Canada.

1. Lenovo ThinkSystem servers support M.2 drives in one of three ways, depending on the server selected: One or two drives, mounted in an M.2 adapter, vertically in a dedicated slot Two or four drives, mounted horizontally in an M.2 adapter Installed directly on the system board.
2. The Lenovo ThinkPad X250 20CL belongs to the category of netbooks i.e. The laptop is smaller than the average computer. For today you can purchase the Lenovo ThinkPad X250 20CL in USA for $999.00. The 12 inch screen size of the notebook can be enough for entertainment however some users may experience inconvenience.

1. Removing the bottom cover

First of all, unlock and remove the battery.
Remove eight screws securing the bottom cover to the laptop.

Lenovo X250 M.2 Slot Ssd

Remove the SD card tray from the laptop.

Here’s the SD card tray.

There are seven clips securing the bottom cover to the body.
You can release the clips with a guitar pick.
Once all clips were released, you can remove the bottom cover.

2. Upgrade the M.2 SSD

Lenovo X250 M.2 Slot 1tb

Under the bottom cover you can get access to the following internal components:
– Hard drive
– RAM module
– M.2 SSD
– Internal battery
– Heat sink and Cooling Fan
– Wireless card
– Speaker
The laptop comes with a 16GB 2242 M.2 SSD. My new M.2 2242 is Transcend MTS400 SATA3 M.2 SSD. By the way, Plextor M6G is also compatible the Lenovo ThinkPad X250.

Remove the screw and take the SSD out of its slot.

Install the Transcend MTS400 SATA3 M.2 SSD into the slot

3. Upgrade the hard drive and 2.5″ SSD

The laptop comes with a Seagate 500GB 7200RPM, and you can upgrade to a larger capacity hard drive, or replace it with a 2.5″ SSD.

In my case, I replace it with a 2.5″ Samsung 850 EVO 250 GB SSD.

4. Upgrade the RAM

The Lenovo ThinkPad X250 comes with an 8GB DDR3L-1600MHz RAM. It has to meet my daily needs, so I did not upgrade the memory, but a user has been upgraded to 16GB, and can be used normally, please see this thread from Lenovo forum.
